Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite
Diamond Segment for Granite

Diamond Segment for Granite

Model NO.
diamond segment
Quantity:

Granite diamond segment has good sharpness and high efficiency at the process of cutting, meanwhile, it has a long lifespan. The sandstone diamond segment has good cutting results: smooth cutting, flat surface, and even size.

Granite segment feature:

1.The blade has good sharpness and high efficiency at the process of cutting, meanwhile, it has a long life span.

2.Good cutting result: smooth cutting, flat surface, and even size.

3.It works in low noise, small cutting slot cutting slot which ensures maximum use of stone uniform thickness.

Machinery

Handheld saw, circular saw, high-speed power saw, Angle grinder, Walk-behind saw low hp, Flat saw, Tile saw, Masonry saw, Stone Saw

Diamond Segment for Granite Application:

General diamond segment used for cutting granite

Parameter Table

Product NameSaw blade Diameter(mm)Segment Dimension(mm)Segment Number(pcs)Shape
Diamond Segment for Granite30040x3.2x10(15,20)21Normal or according to customer's requirement
35040x3.2x10(15,20)24
40040x3.6x10(15,20)28
45040x4.0x10(15,20)32
40040x3.6x10(15,20)28
45040x4.0x10(15,20)32
50040x4.0x10(15,20)36
55040x4.6x10(15,20)40
60040x4.6x10(15,20)42
65040x5.0x10(15,20)46
70040x5.0x10(15,20)50
75040x5.0x10(15,20)54
80040x5.5x10(15,20)57
85040x5.5x10(15,20)58
90024x7.5x13(15)64
100024x7.5x13(15)70
120024x8.0x13(15)80
140024x8.5x13(15)92
160024x9.5x13(15)108
180024x10x13(15)120
200024x11x13(15)128
220024x11x13(15)132
250024x12.5x13(15)140
270024x12.5x13(15)140
  • Edge Type:Segmented
  • Application:Not Rated
